AM6410 Power Sequencer - 翻译中...

Merkmale

● Universal voltage: 100V–240V.
● Equipped with high-quality 30A relays; maximum output per channel: 30A.
● High-power circuits to support large-power electrical systems.
● Voltage display screen shows the current output voltage.
● Chip-controlled, double-sided SMT circuit design for stability and reliability.
● Universal sockets compatible with various plug types.

Jetzt kontaktieren Nachricht hinterlassen

Einführung
Spezifikation

翻译中...

Model	AM6410
Input Power	AC 220V–240V, 50Hz/60Hz
Controlled Channels	8 controlled outputs (universal sockets for global use)
Sequencing Function	Sequential on/off per channel, 1-second interval
Relay Capacity	AC250V / 30A (max output per channel 30A)
Socket Rated Current	AC250V / 10–13A
Max Output Power per Channel	2860W
Max Total Output Power	6600W
Additional Features	Remote control function, built-in power filter
Product Dimensions	430×220×60 mm
Product Weight	4.5kg
